| EN779 Class 标准分级 | F6 | F8 |
| Average Arrestance 效率 | 60-80% | 90-95% |
| Initial Pressure Drop 初阻 | 75 Pa | 110 Pa |
| Final Pressure Drop 终阻 | 400 Pa | |
| Max Operating Temperature 温度 | 250℃ | |
| Frame 框架 | Galvanizhed steel or Aluminum 镀锌板/铝框 | |
| Media 滤媒 | Micro fiberglass paper in mini pleat design | |
| Separators 分隔物 | by microfiberglass cord | |
| Fire Resistance Class 防火 | F1 Din 53438 | |
| Efficiency | Width | Height | Depth | Airflow | Pressure Drop | Filtering Surface |
| mm | mm | mm | m3/h | Pa | ㎡ | |
| F6 | 610 | 610 | 55 | 1800 | 75 | 6.95 |
| F6 | 915 | 457 | 55 | 2000 | 85 | 7.8 |
| F6 | 610 | 610 | 78 | 2000 | 75 | 10.85 |
| F6 | 915 | 457 | 78 | 2000 | 85 | 12.1 |
| F6 | 490 | 592 | 95 | 2450 | 80 | 9 |
| F6 | 592 | 592 | 95 | 3000 | 80 | 11 |
| F8 | 610 | 610 | 55 | 1800 | 90 | 6.95 |
| F8 | 915 | 457 | 55 | 2000 | 110 | 7.8 |
| F8 | 610 | 610 | 78 | 2000 | 90 | 10.85 |
| F8 | 915 | 457 | 78 | 2000 | 110 | 12.1 |
| F8 | 610 | 610 | 120 | 2000 | 120 | 20.4 |
