| 9 Class | F5 | F6 | F7 | F8 | F9 |
| Average Arrestance | 40-60% | 60-80% | 80-90% | 90-95% | >95% |
| Initial Pressure Drop | 35 Pa | 65 Pa | 85 Pa | 95 Pa | 125 Pa |
| Final Pressure Drop | 450 Pa | ||||
| Max Operating Temperature | 120℃ | ||||
| Max.Relative Humidity Resistance | 100% | ||||
| Frame | Galvanizhed steel or Aluminum (20-25mm) | ||||
| Media | Meltblown or rigid synthetic fiber | ||||
| Fire Resistance Class | F1 Din 53438 | ||||
| Efficiency | Width | Height | Depth | Bag Number | Airflow | Pressure Drop | Filtering Surface |
| mm | mm | mm | m3/h | Pa | ㎡ | ||
| F5 | 287 | 287 | 535 | 4 | 850 | 45 | 1.2 |
| F5 | 287 | 287 | 635 | 4 | 850 | 35 | 1.3 |
| F5 | 287 | 592 | 535 | 4 | 1750 | 45 | 2.8 |
| F5 | 287 | 592 | 635 | 4 | 1750 | 35 | 3.4 |
| F5 | 490 | 592 | 535 | 6 | 2850 | 45 | 4.2 |
| F5 | 490 | 592 | 635 | 6 | 2850 | 35 | 5 |
| F5 | 592 | 592 | 535 | 8 | 3400 | 45 | 5.6 |
| F5 | 592 | 592 | 635 | 8 | 3400 | 35 | 7 |
| F6 | 287 | 287 | 535 | 4 | 850 | 75 | 1.2 |
| F6 | 287 | 287 | 635 | 4 | 850 | 65 | 1.3 |
| F6 | 287 | 592 | 535 | 4 | 1750 | 75 | 2.8 |
| F6 | 287 | 592 | 635 | 4 | 1750 | 65 | 3.4 |
| F6 | 490 | 592 | 535 | 6 | 2850 | 75 | 4.2 |
| F6 | 490 | 592 | 635 | 6 | 2850 | 65 | 5 |
| F6 | 592 | 592 | 535 | 8 | 3400 | 75 | 5.6 |
| F6 | 592 | 592 | 635 | 8 | 3400 | 65 | 7 |
| F7 | 287 | 287 | 535 | 4 | 850 | 95 | 1.2 |
| F7 | 287 | 287 | 635 | 4 | 850 | 85 | 1.3 |
| F7 | 287 | 592 | 535 | 4 | 1750 | 95 | 2.8 |
| F7 | 287 | 592 | 635 | 4 | 1750 | 85 | 3.4 |
| F7 | 490 | 592 | 535 | 6 | 2850 | 95 | 4.2 |
| F7 | 490 | 592 | 635 | 6 | 2850 | 85 | 5 |
| F7 | 592 | 592 | 535 | 8 | 3400 | 95 | 5.6 |
| F7 | 592 | 592 | 635 | 8 | 3400 | 85 | 7 |
| F8 | 287 | 287 | 535 | 4 | 850 | 105 | 1.2 |
| F8 | 287 | 287 | 635 | 4 | 850 | 95 | 1.3 |
| F8 | 287 | 592 | 535 | 4 | 1750 | 105 | 2.8 |
| F8 | 287 | 592 | 635 | 4 | 1750 | 95 | 3.4 |
| F8 | 490 | 592 | 535 | 6 | 2850 | 105 | 4.2 |
| F8 | 490 | 592 | 635 | 6 | 2850 | 95 | 5 |
| F8 | 592 | 592 | 535 | 8 | 3400 | 105 | 5.6 |
| F8 | 592 | 592 | 635 | 8 | 3400 | 95 | 7 |
