FILTER CLASS(EN1822) | H11 | H13 | H14 | U15 |
Global Efficiency % for MPPS | ≥95% | ≥99.95% | ≥99.995% | ≥99.9995% |
Local Efficiency % for MPPS | - | 99.75% | 99.98% | 99.9975% |
Recommended Final Pressure Drop | 600Pa | 600Pa | 600Pa | 600Pa |
Max.Final Pressure Drop | 1000Pa | 1000Pa | 1000Pa | 1000Pa |
Continuous Temperature Resistance | 80℃ | 80℃ | 80℃ | 80℃ |
Max.Relative Humidity Resistance | 100% | 100% | 100% | 100% |
Frame | Aluminium and MDF | |||
Face Guard | Epoxy painted expanded aluminium grids on both sides | |||
Gasket | One piece foamed polyurethane | |||
Fire Resistance Class | K1/F1 according to DIN53438 | |||
Filter Stage | III | |||
TESTING | Each filter individually tested according to EN 1822 | |||
For MDF Frame filter one and two side with protective girds optional |
